Zupt’s Subsea Static Heading Sensor Delivers Real-Time ROV Orientation Data

7 August 2026
Edited By: Ed Freeman

Zupt's Subsea Static Heading Sensor has demonstrated how heading, pitch, and roll can be quickly measured on a subsea structure. The Subsea Static Heading Sensor is a compact, self-contained device for measuring subsea structure orientation. It provides real-time pitch, roll, and heading readings on an onboard display without requiring external communications or acoustic links. Designed for remotely operated vehicle (ROV) deployment, it can be placed onto a structure and read immediately from up to 3+ meters away.

(Image Credit: Zupt)

At its core is a MEMS Inertial Measurement Unit (IMU) in a titanium housing rated to 4,000 meters. Optional motorized rotation enables quadrant-based gyrocompassing, delivering heading performance approaching that of high-end inertial navigation systems, but without the associated cost. Continuous onboard accelerometers provide pitch and roll readings with <0.1° accuracy, while heading achieves up to ±1°, depending on the chosen IMU.

Durable, compact, and ROV-ready, the Subsea Static Heading Sensor delivers reliable orientation measurements to support efficient subsea operations.

The LED display is optimized for seawater visibility and can be read clearly by ROV cameras without requiring data out. Colors are customizable, and the display angle adjusts to suit the deployment environment. A rechargeable internal battery provides at least eight hours of operation, with automatic activation on deployment and power conservation until the device is rotated or moved. Its modular design supports future upgrades without replacing the housing, ensuring long-term flexibility and value.
